3830 Series
HTT, or OEM job
HPP
To drill holes in stone ware drilling of 4 and 5 class, especially glaze, sandstone, glazed sandstone, sandware, Terracota, marble, tiles upto 5th class.
3830
6mm to 25mm
Hex Shank
Masonry work
| Quantity: | |
|---|---|
Size Table:
| Item Number | Diameter(mm) | Max.Cutting Depth(mm) | Overall Length(mm) |
| 3830.0602255 | 6 | 22 | 55 |
| 3830.0652255 | 6.5 | 22 | 55 |
| 3830.0702255 | 7 | 22 | 55 |
| 3830.0802055 | 8 | 20 | 55 |
| 3830.1003065 | 10 | 30 | 65 |
| 3830.1202865 | 12 | 28 | 65 |
| 3830.1302865 | 13 | 28 | 65 |
| 3830.1504070 | 15 | 40 | 70 |
| 3830.1804070 | 18 | 40 | 70 |
| 3830.2004070 | 20 | 40 | 70 |
| 3830.2204070 | 22 | 40 | 70 |
| 3830.2504070 | 25 | 40 | 70 |
