3115 Series
HTT, OEM job
MPP
To drill holes in various concrete, masonry building material wall, floor, etc.
3115
3 to 25mm
Cylinder
Masonry work
| Quantity: | |
|---|---|
Size Table:
*Note: Diameter 14mm to 25mm ones are with the reduced cylinder shank.
Item Number | Diameter（mm） | Working Length（mm） | Overall Length（mm） |
3115.030060 | 3 | 30 | 60 |
3115.030070 | 3 | 35 | 70 |
3115.030085 | 3 | 45 | 85 |
3115.040075 | 4 | 35 | 75 |
3115.040085 | 4 | 45 | 85 |
3115.040090 | 4 | 50 | 90 |
3115.040150 | 4 | 110 | 150 |
3115.050085 | 5 | 40 | 85 |
3115.050090 | 5 | 45 | 90 |
3115.050095 | 5 | 50 | 95 |
3115.050100 | 5 | 60 | 100 |
3115.050150 | 5 | 110 | 150 |
3115.050250 | 5 | 200 | 250 |
3115.050300 | 5 | 250 | 300 |
3115.050400 | 5 | 260 | 400 |
3115.050500 | 5 | 360 | 500 |
3115.055095 | 5.5 | 50 | 95 |
3115.055100 | 5.5 | 60 | 100 |
3115.055150 | 5.5 | 110 | 150 |
3115.060100 | 6 | 60 | 100 |
3115.060150 | 6 | 110 | 150 |
3115.060200 | 6 | 130 | 200 |
3115.060260 | 6 | 190 | 260 |
3115.060300 | 6 | 230 | 300 |
3115.060400 | 6 | 340 | 400 |
3115.060600 | 6 | 460 | 600 |
3115.065100 | 6.5 | 60 | 100 |
3115.065150 | 6.5 | 110 | 150 |
3115.065200 | 6.5 | 130 | 200 |
3115.065260 | 6.5 | 190 | 260 |
3115.065300 | 6.5 | 230 | 300 |
3115.065400 | 6.5 | 340 | 400 |
3115.070100 | 7 | 60 | 100 |
3115.070120 | 7 | 80 | 120 |
3115.070150 | 7 | 110 | 150 |
3115.070300 | 7 | 230 | 300 |
3115.070400 | 7 | 340 | 400 |
3115.070500 | 7 | 360 | 500 |
3115.080120 | 8 | 80 | 120 |
3115.080150 | 8 | 110 | 150 |
3115.080200 | 8 | 130 | 200 |
3115.080260 | 8 | 190 | 260 |
3115.080300 | 8 | 230 | 300 |
3115.080400 | 8 | 340 | 400 |
3115.080600 | 8 | 460 | 600 |
3115.090120 | 9 | 80 | 120 |
3115.090150 | 9 | 110 | 150 |
3115.100120 | 10 | 80 | 120 |
3115.100150 | 10 | 110 | 150 |
3115.100200 | 10 | 135 | 200 |
3115.100260 | 10 | 190 | 260 |
3115.100300 | 10 | 230 | 300 |
3115.100400 | 10 | 340 | 400 |
3115.100600 | 10 | 460 | 600 |
3115.120130 | 12 | 80 | 130 |
3115.120150 | 12 | 90 | 150 |
3115.120200 | 12 | 150 | 200 |
3115.120260 | 12 | 150 | 260 |
3115.120300 | 12 | 230 | 300 |
3115.120400 | 12 | 340 | 400 |
3115.120600 | 12 | 460 | 600 |
3115.121000 | 12 | 900 | 1000 |
3115.130150 | 13 | 90 | 150 |
3115.130200 | 13 | 150 | 200 |
3115.130300 | 13 | 230 | 300 |
3115.140150 | 14 | 90 | 150 |
3115.140200 | 14 | 135 | 200 |
3115.140260 | 14 | 200 | 260 |
3115.140300 | 14 | 230 | 300 |
3115.140400 | 14 | 340 | 400 |
3115.140600 | 14 | 460 | 600 |
3115.160150 | 16 | 90 | 150 |
3115.160200 | 16 | 135 | 200 |
3115.160250 | 16 | 200 | 260 |
3115.160300 | 16 | 230 | 300 |
3115.160400 | 16 | 340 | 400 |
3115.160600 | 16 | 460 | 600 |
3115.180160 | 18 | 100 | 160 |
3115.180200 | 18 | 135 | 200 |
3115.180300 | 18 | 230 | 300 |
3115.180400 | 18 | 340 | 400 |
3115.180600 | 18 | 460 | 600 |
3115.200160 | 20 | 100 | 160 |
3115.200200 | 20 | 135 | 200 |
3115.200260 | 20 | 200 | 260 |
3115.200300 | 20 | 230 | 300 |
3115.200400 | 20 | 340 | 400 |
3115.200600 | 20 | 460 | 600 |
3115.220160 | 22 | 100 | 160 |
3115.220200 | 22 | 135 | 200 |
3115.220300 | 22 | 230 | 300 |
3115.220400 | 22 | 340 | 400 |
3115.250160 | 25 | 100 | 160 |
3115.250200 | 25 | 135 | 200 |
3115.250300 | 25 | 230 | 300 |
3115.250400 | 25 | 340 | 400 |
