7012
HTT, OEM job
MPP+
To drill holes in various concrete, brick, stone, etc. to finish sanitary and renovation works
7012
30-150mm;1-3/16" to 6"
Cone-shaped
Masonry work
| Quantity: | |
|---|---|
Size Table:
DIN metric standard
| Item Number | Diameter(mm) | Max. Cutting Depth(mm) | Overall Length(mm) | Threaded Conneting |
| 7012.030100 | 30 | 75 | 100 | Cone-shaped hole |
| 7012.035100 | 35 | 75 | 100 | Cone-shaped hole |
| 7012.040100 | 40 | 75 | 100 | Cone-shaped hole |
| 7012.045100 | 45 | 75 | 100 | Cone-shaped hole |
| 7012.050100 | 50 | 75 | 100 | Cone-shaped hole |
| 7012.060100 | 60 | 75 | 100 | Cone-shaped hole |
| 7012.066100 | 66 | 75 | 100 | Cone-shaped hole |
| 7012.068100 | 68 | 75 | 100 | Cone-shaped hole |
| 7012.070100 | 70 | 75 | 100 | Cone-shaped hole |
| 7012.080100 | 80 | 75 | 100 | Cone-shaped hole |
| 7012.090100 | 90 | 75 | 100 | Cone-shaped hole |
| 7012.100100 | 100 | 75 | 100 | Cone-shaped hole |
| 7012.110100 | 110 | 75 | 100 | Cone-shaped hole |
| 7012.125100 | 125 | 75 | 100 | Cone-shaped hole |
| 7012.150100 | 150 | 75 | 100 | Cone-shaped hole |
| 7012.110120 | TCT Pilot Drill Bit with Cone-shaped shank , 11mm diameter x 90mm working length x 120mm overall length | |||
| 7012.220000 | 220mm OL adapter with SDS-max shank and Cone-shaped head | |||
| 7012.420000 | 420mm OL adapter with SDS-max shank and Cone-shaped head | |||
| 7012.700000 | 700mm OL adapter with SDS-max shank and Cone-shaped head | |||
| 7012.900000 | 900mm OL adapter with SDS-max shank and Cone-shaped head | |||
| 7012.000011 | Extraction Key with Ring chain | |||
Size Table:
ANSI standard
| Item Number | Diameter(inch) | Diameter(mm) | Max. Cutting Depth(inch) | Overall Length(inch) | Threaded Conneting |
| 7012.1316004 | 1-3/16" | 30 | 3" | 4" | Cone-shaped hole |
| 7012.1308004 | 1-3/8" | 35 | 3" | 4" | Cone-shaped hole |
| 7012.1102600 | 1-1/2" | 38 | 3" | 4" | Cone-shaped hole |
| 7012.1304004 | 1-3/4" | 45 | 3" | 4" | Cone-shaped hole |
| 7012.2000004 | 2" | 51 | 3" | 4" | Cone-shaped hole |
| 7012.2104004 | 2-1/4" | 57 | 3" | 4" | Cone-shaped hole |
| 7012.2508004 | 2-5/8" | 67 | 3" | 4" | Cone-shaped hole |
| 7012.2304004 | 2-3/4" | 70 | 3" | 4" | Cone-shaped hole |
| 7012.3108004 | 3-1/8" | 79 | 3" | 4" | Cone-shaped hole |
| 7012.3916004 | 3-9/16" | 90 | 3" | 4" | Cone-shaped hole |
| 7012.4000004 | 4" | 102 | 3" | 4" | Cone-shaped hole |
| 7012.4308004 | 4-3/8" | 111 | 3" | 4" | Cone-shaped hole |
| 7012.5000004 | 5" | 127 | 3" | 4" | Cone-shaped hole |
| 7012.6000004 | 6" | 152 | 3" | 4" | Cone-shaped hole |
| 7012.0716412 | TCT Pilot Drill Bit with flat , 7/16" diameter x 3-1/2" working length x 4-1/2" overall length | ||||
| 7012.0800001 | 8" OL adapter with SDS-plus shank and fixing screw, hex wrench, Cone-shaped head | ||||
| 7012.1600001 | 16" OL adapter with SDS-plus shank and fixing screw, hex wrench, Cone-shaped head | ||||
| 7012.2700001 | 27" OL adapter with SDS-plus shank and fixing screw, hex wrench, Cone-shaped head | ||||
| 7012.3500001 | 35" OL adapter with SDS-plus shank and fixing screw, hex wrench, Cone-shaped head | ||||
| 7012.0000011 | Extraction Key with Ring chain | ||||
Size Table:
DIN metric standard
| Item Number | Diameter(mm) | Max. Cutting Depth(mm) | Overall Length(mm) | Threaded Conneting |
| 7012.030100 | 30 | 75 | 100 | Cone-shaped hole |
| 7012.035100 | 35 | 75 | 100 | Cone-shaped hole |
| 7012.040100 | 40 | 75 | 100 | Cone-shaped hole |
| 7012.045100 | 45 | 75 | 100 | Cone-shaped hole |
| 7012.050100 | 50 | 75 | 100 | Cone-shaped hole |
| 7012.060100 | 60 | 75 | 100 | Cone-shaped hole |
| 7012.066100 | 66 | 75 | 100 | Cone-shaped hole |
| 7012.068100 | 68 | 75 | 100 | Cone-shaped hole |
| 7012.070100 | 70 | 75 | 100 | Cone-shaped hole |
| 7012.080100 | 80 | 75 | 100 | Cone-shaped hole |
| 7012.090100 | 90 | 75 | 100 | Cone-shaped hole |
| 7012.100100 | 100 | 75 | 100 | Cone-shaped hole |
| 7012.110100 | 110 | 75 | 100 | Cone-shaped hole |
| 7012.125100 | 125 | 75 | 100 | Cone-shaped hole |
| 7012.150100 | 150 | 75 | 100 | Cone-shaped hole |
| 7012.110120 | TCT Pilot Drill Bit with Cone-shaped shank , 11mm diameter x 90mm working length x 120mm overall length | |||
| 7012.220000 | 220mm OL adapter with SDS-max shank and Cone-shaped head | |||
| 7012.420000 | 420mm OL adapter with SDS-max shank and Cone-shaped head | |||
| 7012.700000 | 700mm OL adapter with SDS-max shank and Cone-shaped head | |||
| 7012.900000 | 900mm OL adapter with SDS-max shank and Cone-shaped head | |||
| 7012.000011 | Extraction Key with Ring chain | |||
Size Table:
ANSI standard
| Item Number | Diameter(inch) | Diameter(mm) | Max. Cutting Depth(inch) | Overall Length(inch) | Threaded Conneting |
| 7012.1316004 | 1-3/16" | 30 | 3" | 4" | Cone-shaped hole |
| 7012.1308004 | 1-3/8" | 35 | 3" | 4" | Cone-shaped hole |
| 7012.1102600 | 1-1/2" | 38 | 3" | 4" | Cone-shaped hole |
| 7012.1304004 | 1-3/4" | 45 | 3" | 4" | Cone-shaped hole |
| 7012.2000004 | 2" | 51 | 3" | 4" | Cone-shaped hole |
| 7012.2104004 | 2-1/4" | 57 | 3" | 4" | Cone-shaped hole |
| 7012.2508004 | 2-5/8" | 67 | 3" | 4" | Cone-shaped hole |
| 7012.2304004 | 2-3/4" | 70 | 3" | 4" | Cone-shaped hole |
| 7012.3108004 | 3-1/8" | 79 | 3" | 4" | Cone-shaped hole |
| 7012.3916004 | 3-9/16" | 90 | 3" | 4" | Cone-shaped hole |
| 7012.4000004 | 4" | 102 | 3" | 4" | Cone-shaped hole |
| 7012.4308004 | 4-3/8" | 111 | 3" | 4" | Cone-shaped hole |
| 7012.5000004 | 5" | 127 | 3" | 4" | Cone-shaped hole |
| 7012.6000004 | 6" | 152 | 3" | 4" | Cone-shaped hole |
| 7012.0716412 | TCT Pilot Drill Bit with flat , 7/16" diameter x 3-1/2" working length x 4-1/2" overall length | ||||
| 7012.0800001 | 8" OL adapter with SDS-plus shank and fixing screw, hex wrench, Cone-shaped head | ||||
| 7012.1600001 | 16" OL adapter with SDS-plus shank and fixing screw, hex wrench, Cone-shaped head | ||||
| 7012.2700001 | 27" OL adapter with SDS-plus shank and fixing screw, hex wrench, Cone-shaped head | ||||
| 7012.3500001 | 35" OL adapter with SDS-plus shank and fixing screw, hex wrench, Cone-shaped head | ||||
| 7012.0000011 | Extraction Key with Ring chain | ||||
