701-PS
OEM, 3WIN, HTT
HPP
To cut the materials of various plastic sheets, thermoplastic boards, etc.
701-PS
305mm - 550mm
Bushings available on customers' request
Wood work
| Quantity: | |
|---|---|
Size Table:
| Item Number | Diameter(mm) | Diameter(inch) | Teeth QTY. | Kerf | Body Kerf | Bore | Pinhole | Form | Machine Name |
| 701.PS3054830 | 305 | 12" | 48 | 4.4mm | 3mm | 30mm | - | TCG | Panhans, Hoggers, Mayer |
| 701.PS3056030 | 305 | 12" | 60 | 4.4mm | 3mm | 30mm | - | TCG | Panhans, Hoggers, Mayer |
| 701.PS3056075 | 305 | 12" | 60 | 4.4mm | 3mm | 75mm | - | TCG | |
| 701.PS3555475 | 355 | 14" | 54 | 4.4mm | 3mm | 75mm | - | TCG | Gibben |
| 701.PS3557230 | 355 | 14" | 72 | 4.4mm | 3mm | 30mm | - | TCG | Panhans, SCM, Mayer |
| 701.PS3557275 | 355 | 14" | 72 | 4.4mm | 3mm | 75mm | - | TCG | Gibben |
| 701.PS3557280 | 355 | 14" | 72 | 4.4mm | 3mm | 80mm | 4/2 PH | TCG | Gabbiani, S.M.A. |
| 701.PS3806060 | 380 | 60 | 4.4mm | 3mm | 60mm | 4 PH | TCG | Holzma | |
| 701.PS3807260 | 380 | 72 | 4.8mm | 3.5mm | 60mm | 2 PH | TCG | Beam | |
| 701.PS3807280 | 380 | 72 | 4.8mm | 3.5mm | 80mm | 8 PH | TCG | SCM+Gabbiani | |
| 701.PS3907250 | 390 | 72 | 4.4mm | 3.5mm | 50mm | 4 PH | TCG | ||
| 701.PS4006030 | 400 | 16" | 60 | 4.4mm | 3.2mm | 30mm | - | ATB | |
| 701.PS4016030 | 400 | 16" | 60 | 4.4mm | 3.2mm | 30mm | - | TCG | Schelling, Mayer |
| 701.PS4006075 | 400 | 16" | 60 | 4.4mm | 3.2mm | 75mm | - | TCG | Gibben |
| 701.PS4006080 | 400 | 16" | 60 | 4.4mm | 3.2mm | 80mm | 4/2 PH | TCG | Gabbiani |
| 701.PS4007230 | 400 | 16" | 72 | 4.25mm | 3.2mm | 30mm | - | TCG | Scher |
| 701.PS4017230 | 400 | 16" | 72 | 4.4mm | 3.2mm | 30mm | - | TCG | Scher, Schelling |
| 701.PS4007260 | 400 | 16" | 72 | 4.4mm | 3.2mm | 60mm | - | TCG | Holzma, Anthon |
| 701.PS4007275 | 400 | 16" | 72 | 4.4mm | 3.2mm | 75mm | - | TCG | Gibben |
| 701.PS4017275 | 400 | 16" | 72 | 4.4mm | 3.2mm | 75mm | 4 PH | TCG | Gibben |
| 701.PS4027280 | 400 | 16" | 72 | 4.4mm | 3.2mm | 80mm | 4 PH | ATB | |
| 701.PS4037280 | 400 | 16" | 72 | 4.4mm | 3.2mm | 80mm | 8 PH | TCG | Gabbiani |
| 701.PS4047280 | 400 | 16" | 72 | 4.4mm | 3.2mm | 80mm | 2 PH | TCG | Selco, S.M.A. |
| 701.PS4207260 | 420 | 72 | 4.4mm | 3.2mm | 60mm | - | TCG | Holzma | |
| 701.PS4207260 | 420 | 72 | 4.8mm | 3.5mm | 60mm | - | TCG | Holzma | |
| 701.PS4307230 | 430 | 72 | 4.4mm | 3.2mm | 30mm | - | TCG | Panhans, Hoggers, Mayer | |
| 701.PS4307280 | 430 | 72 | 4.4mm | 3.2mm | 80mm | 2 PH | TCG | Selco, S.M.A. | |
| 701.PS4309650 | 430 | 96 | 4.4mm | 3.2mm | 50mm | 3 PH | TCG | Gibben | |
| 701.PS4309675 | 430 | 96 | 4.4mm | 3.2mm | 75mm | 4 PH | TCG | Gibben | |
| 701.PS4507230 | 450 | 18" | 72 | 4.4mm | 3.2mm | 30mm | - | TCG | Panhans |
| 701.PS4507260 | 450 | 18" | 72 | 4.4mm | 3.2mm | 60mm | - | TCG | Holzma |
| 701.PS4507275 | 450 | 18" | 72 | 4.4mm | 3.2mm | 75mm | - | TCG | Gibben |
| 701.PS4507280 | 450 | 18" | 72 | 4.4mm | 3.2mm | 80mm | 2 PH | ATB | |
| 701.PS4517280 | 450 | 18" | 72 | 4.4mm | 3.2mm | 80mm | 2 PH | TCG | Selco, S.M.A. |
| 701.PS4527280 | 450 | 18" | 72 | 4.6mm | 3.5mm | 80mm | 2 PH | TCG | Selco |
| 701.PS4537280 | 450 | 18" | 72 | 4.8mm | 3.5mm | 80mm | 2 PH | TCG | Selco |
| 701.PS4517260 | 450 | 18" | 72 | 4.8mm | 3.5mm | 60mm | 2 PH | TCG | Holzma |
| 701.PS4709675 | 470 | 96 | 4.4mm | 3.2mm | 75mm | 4 PH | TCG | Gibben | |
| 701.PS5006060 | 500 | 20" | 60 | 4.8mm | 3.5mm | 60mm | - | TCG | Holzma |
| 701.PS5007275 | 500 | 20" | 72 | 4.4mm | 3.2mm | 75mm | - | TCG | Gibben |
| 701.PS5007260 | 500 | 20" | 72 | 4.8mm | 3.5mm | 60mm | - | TCG | Holzma, Anthon |
| 701.PS5017275 | 500 | 20" | 72 | 4.8mm | 3.5mm | 75mm | - | TCG | Gibben |
| 701.PS5007280 | 500 | 20" | 72 | 4.8mm | 3.5mm | 80mm | 2 PH | TCG | Teutomatic |
| 701.PS5017260 | 500 | 20" | 72 | 5.0mm | 3.5mm | 60mm | - | TCG | Holzma |
| 701.PS5037275 | 500 | 20" | 72 | 5.0mm | 3.5mm | 75mm | - | TCG | Gibben |
| 701.PS55072100 | 550 | 22" | 72 | 5.0mm | 3.5mm | 100mm | - | TCG | Gibben |
