333-LH Series
HTT, OEM job
MPP
To drill holes in various wood, chipboard, laminated wood, fibre wood, rough wood, rubber wood,etc.
333-LH
6mm to 36mm
Hex
Wood work
| Quantity: | |
|---|---|
Size Table:
| Item Number | Diameter(mm) | Spiral flute length(mm) | Overall Length(mm) | Hex Shank Diameter(mm) |
| 333.10062302 | 6 | 160 | 230 | 5.2 |
| 333.10072302 | 7 | 160 | 230 | 6.1 |
| 333.10082302 | 8 | 160 | 230 | 7 |
| 333.10092302 | 9 | 160 | 230 | 7.2 |
| 333.10102302 | 10 | 160 | 230 | 7.2 |
| 333.10112302 | 11 | 160 | 230 | 7.2 |
| 333.10122302 | 12 | 160 | 230 | 7.2 |
| 333.10132302 | 13 | 160 | 230 | 9.1 |
| 333.10142302 | 14 | 160 | 230 | 9.1 |
| 333.10152302 | 15 | 160 | 230 | 9.1 |
| 333.10162302 | 16 | 160 | 230 | 9.1 |
| 333.10182302 | 18 | 160 | 230 | 9.1 |
| 333.10192302 | 19 | 160 | 230 | 10.9 |
| 333.10202302 | 20 | 160 | 230 | 10.9 |
| 333.10212302 | 21 | 160 | 230 | 10.9 |
| 333.10222302 | 22 | 160 | 230 | 10.9 |
| 333.10242302 | 24 | 160 | 230 | 10.9 |
| 333.10252302 | 25 | 160 | 230 | 10.9 |
| 333.10262302 | 26 | 160 | 230 | 10.9 |
| 333.10272302 | 27 | 160 | 230 | 10.9 |
| 333.10282302 | 28 | 160 | 230 | 10.9 |
| 333.10302302 | 30 | 160 | 230 | 10.9 |
| 333.10322302 | 32 | 160 | 230 | 10.9 |
| 333.10332302 | 33 | 160 | 230 | 10.9 |
| 333.10342302 | 34 | 160 | 230 | 10.9 |
| 333.10352302 | 35 | 160 | 230 | 10.9 |
| 333.10362302 | 36 | 160 | 230 | 10.9 |
| Item Number | Diameter(mm) | Spiral flute length(mm) | Overall Length(mm) | Hex Shank Diameter(mm) |
| 333.10064602 | 6 | 390 | 460 | 5.2 |
| 333.10074602 | 7 | 390 | 460 | 6.1 |
| 333.10084602 | 8 | 390 | 460 | 7 |
| 333.10094602 | 9 | 390 | 460 | 7.2 |
| 333.10104602 | 10 | 390 | 460 | 7.2 |
| 333.10114602 | 11 | 390 | 460 | 7.2 |
| 333.10124602 | 12 | 390 | 460 | 7.2 |
| 333.10134602 | 13 | 390 | 460 | 9.1 |
| 333.10144602 | 14 | 390 | 460 | 9.1 |
| 333.10154602 | 15 | 390 | 460 | 9.1 |
| 333.10164602 | 16 | 390 | 460 | 9.1 |
| 333.10184602 | 18 | 390 | 460 | 9.1 |
| 333.10194602 | 19 | 390 | 460 | 10.9 |
| 333.10204602 | 20 | 390 | 460 | 10.9 |
| 333.10214602 | 21 | 390 | 460 | 10.9 |
| 333.10224602 | 22 | 390 | 460 | 10.9 |
| 333.10244602 | 24 | 390 | 460 | 10.9 |
| 333.10254602 | 25 | 390 | 460 | 10.9 |
| 333.10264602 | 26 | 390 | 460 | 10.9 |
| 333.10274602 | 27 | 390 | 460 | 10.9 |
| 333.10284602 | 28 | 390 | 460 | 10.9 |
| 333.10304602 | 30 | 390 | 460 | 10.9 |
| 333.10324602 | 32 | 390 | 460 | 10.9 |
| 333.10334602 | 33 | 390 | 460 | 10.9 |
| 333.10344602 | 34 | 390 | 460 | 10.9 |
| 333.10354602 | 35 | 390 | 460 | 10.9 |
| 333.10364602 | 36 | 390 | 460 | 10.9 |
| Item Number | Diameter(mm) | Spiral flute length(mm) | Overall Length(mm) | Hex Shank Diameter(mm) |
| 333.10066002 | 6 | 530 | 600 | 5.2 |
| 333.10076002 | 7 | 530 | 600 | 6.1 |
| 333.10086002 | 8 | 530 | 600 | 7 |
| 333.10096002 | 9 | 530 | 600 | 7.2 |
| 333.10106002 | 10 | 530 | 600 | 7.2 |
| 333.10116002 | 11 | 530 | 600 | 7.2 |
| 333.10126002 | 12 | 530 | 600 | 7.2 |
| 333.10136002 | 13 | 530 | 600 | 9.1 |
| 333.10146002 | 14 | 530 | 600 | 9.1 |
| 333.10156002 | 15 | 530 | 600 | 9.1 |
| 333.10166002 | 16 | 530 | 600 | 9.1 |
| 333.10186002 | 18 | 530 | 600 | 9.1 |
| 333.10196002 | 19 | 530 | 600 | 10.9 |
| 333.10206002 | 20 | 530 | 600 | 10.9 |
| 333.10216002 | 21 | 530 | 600 | 10.9 |
| 333.10226002 | 22 | 530 | 600 | 10.9 |
| 333.10246002 | 24 | 530 | 600 | 10.9 |
| 333.10256002 | 25 | 530 | 600 | 10.9 |
| 333.10266002 | 26 | 530 | 600 | 10.9 |
| 333.10276002 | 27 | 530 | 600 | 10.9 |
| 333.10286002 | 28 | 530 | 600 | 10.9 |
| 333.10306002 | 30 | 530 | 600 | 10.9 |
| 333.10326002 | 32 | 530 | 600 | 10.9 |
| 333.10336002 | 33 | 530 | 600 | 10.9 |
| 333.10346002 | 34 | 530 | 600 | 10.9 |
| 333.10356002 | 35 | 530 | 600 | 10.9 |
| 333.10360602 | 36 | 530 | 600 | 10.9 |
Size Table:
| Item Number | Diameter(mm) | Spiral flute length(mm) | Overall Length(mm) | Hex Shank Diameter(mm) |
| 333.10062302 | 6 | 160 | 230 | 5.2 |
| 333.10072302 | 7 | 160 | 230 | 6.1 |
| 333.10082302 | 8 | 160 | 230 | 7 |
| 333.10092302 | 9 | 160 | 230 | 7.2 |
| 333.10102302 | 10 | 160 | 230 | 7.2 |
| 333.10112302 | 11 | 160 | 230 | 7.2 |
| 333.10122302 | 12 | 160 | 230 | 7.2 |
| 333.10132302 | 13 | 160 | 230 | 9.1 |
| 333.10142302 | 14 | 160 | 230 | 9.1 |
| 333.10152302 | 15 | 160 | 230 | 9.1 |
| 333.10162302 | 16 | 160 | 230 | 9.1 |
| 333.10182302 | 18 | 160 | 230 | 9.1 |
| 333.10192302 | 19 | 160 | 230 | 10.9 |
| 333.10202302 | 20 | 160 | 230 | 10.9 |
| 333.10212302 | 21 | 160 | 230 | 10.9 |
| 333.10222302 | 22 | 160 | 230 | 10.9 |
| 333.10242302 | 24 | 160 | 230 | 10.9 |
| 333.10252302 | 25 | 160 | 230 | 10.9 |
| 333.10262302 | 26 | 160 | 230 | 10.9 |
| 333.10272302 | 27 | 160 | 230 | 10.9 |
| 333.10282302 | 28 | 160 | 230 | 10.9 |
| 333.10302302 | 30 | 160 | 230 | 10.9 |
| 333.10322302 | 32 | 160 | 230 | 10.9 |
| 333.10332302 | 33 | 160 | 230 | 10.9 |
| 333.10342302 | 34 | 160 | 230 | 10.9 |
| 333.10352302 | 35 | 160 | 230 | 10.9 |
| 333.10362302 | 36 | 160 | 230 | 10.9 |
| Item Number | Diameter(mm) | Spiral flute length(mm) | Overall Length(mm) | Hex Shank Diameter(mm) |
| 333.10064602 | 6 | 390 | 460 | 5.2 |
| 333.10074602 | 7 | 390 | 460 | 6.1 |
| 333.10084602 | 8 | 390 | 460 | 7 |
| 333.10094602 | 9 | 390 | 460 | 7.2 |
| 333.10104602 | 10 | 390 | 460 | 7.2 |
| 333.10114602 | 11 | 390 | 460 | 7.2 |
| 333.10124602 | 12 | 390 | 460 | 7.2 |
| 333.10134602 | 13 | 390 | 460 | 9.1 |
| 333.10144602 | 14 | 390 | 460 | 9.1 |
| 333.10154602 | 15 | 390 | 460 | 9.1 |
| 333.10164602 | 16 | 390 | 460 | 9.1 |
| 333.10184602 | 18 | 390 | 460 | 9.1 |
| 333.10194602 | 19 | 390 | 460 | 10.9 |
| 333.10204602 | 20 | 390 | 460 | 10.9 |
| 333.10214602 | 21 | 390 | 460 | 10.9 |
| 333.10224602 | 22 | 390 | 460 | 10.9 |
| 333.10244602 | 24 | 390 | 460 | 10.9 |
| 333.10254602 | 25 | 390 | 460 | 10.9 |
| 333.10264602 | 26 | 390 | 460 | 10.9 |
| 333.10274602 | 27 | 390 | 460 | 10.9 |
| 333.10284602 | 28 | 390 | 460 | 10.9 |
| 333.10304602 | 30 | 390 | 460 | 10.9 |
| 333.10324602 | 32 | 390 | 460 | 10.9 |
| 333.10334602 | 33 | 390 | 460 | 10.9 |
| 333.10344602 | 34 | 390 | 460 | 10.9 |
| 333.10354602 | 35 | 390 | 460 | 10.9 |
| 333.10364602 | 36 | 390 | 460 | 10.9 |
| Item Number | Diameter(mm) | Spiral flute length(mm) | Overall Length(mm) | Hex Shank Diameter(mm) |
| 333.10066002 | 6 | 530 | 600 | 5.2 |
| 333.10076002 | 7 | 530 | 600 | 6.1 |
| 333.10086002 | 8 | 530 | 600 | 7 |
| 333.10096002 | 9 | 530 | 600 | 7.2 |
| 333.10106002 | 10 | 530 | 600 | 7.2 |
| 333.10116002 | 11 | 530 | 600 | 7.2 |
| 333.10126002 | 12 | 530 | 600 | 7.2 |
| 333.10136002 | 13 | 530 | 600 | 9.1 |
| 333.10146002 | 14 | 530 | 600 | 9.1 |
| 333.10156002 | 15 | 530 | 600 | 9.1 |
| 333.10166002 | 16 | 530 | 600 | 9.1 |
| 333.10186002 | 18 | 530 | 600 | 9.1 |
| 333.10196002 | 19 | 530 | 600 | 10.9 |
| 333.10206002 | 20 | 530 | 600 | 10.9 |
| 333.10216002 | 21 | 530 | 600 | 10.9 |
| 333.10226002 | 22 | 530 | 600 | 10.9 |
| 333.10246002 | 24 | 530 | 600 | 10.9 |
| 333.10256002 | 25 | 530 | 600 | 10.9 |
| 333.10266002 | 26 | 530 | 600 | 10.9 |
| 333.10276002 | 27 | 530 | 600 | 10.9 |
| 333.10286002 | 28 | 530 | 600 | 10.9 |
| 333.10306002 | 30 | 530 | 600 | 10.9 |
| 333.10326002 | 32 | 530 | 600 | 10.9 |
| 333.10336002 | 33 | 530 | 600 | 10.9 |
| 333.10346002 | 34 | 530 | 600 | 10.9 |
| 333.10356002 | 35 | 530 | 600 | 10.9 |
| 333.10360602 | 36 | 530 | 600 | 10.9 |
