Nail-cut Ship Auger Bit Lewis Style Quick Change Hex Shank
You are here: Home » Products » Wood Drill Bit » Ship auger drill » Nail-cut Ship Auger Bit Lewis Style Quick Change Hex Shank
PRODUCTS

Categories

Search Products

Hot Keywords:
Product Inquiry

loading

Share to:
sharethis sharing button

Nail-cut Ship Auger Bit Lewis Style Quick Change Hex Shank

1, For heavy duty, precision drilling in soft and hard wood with the nail-embedded, large section beams, joints, floor boarding, chipboard and plywood.
2, Lewis flute design for rapid chip removal.
3, With quick change hex shank for secure chuck grip to fit those quick-change hex shank chucks and connectors
4, Self-feeding design on higher efficiency work to drill various wood, plywood, etc.

  • 333NC Series

  • HTT, OEM job

  • HPP

  • To drill holes in various wood, chipboard, laminated wood, fibre wood, rough wood, rubber wood,etc.

  • 333NC

  • 6mm to 36mm

  • Quick Change Hex Shank

  • Wood work

Availability:
Quantity:
Inquire Add to Basket

Size Table:

Item Number Diameter(mm) Spiral flute length(mm) Overall Length(mm) Quick Change Hex Shank Standard
333NC.10062302 6 160 230 DIN6.35E
333NC.10072302 7 160 230 DIN6.35E
333NC.10082302 8 160 230 DIN6.35E
333NC.10092302 9 160 230 DIN6.35E
333NC.10102302 10 160 230 DIN6.35E
333NC.10112302 11 160 230 DIN6.35E
333NC.10122302 12 160 230 DIN6.35E
333NC.10132302 13 160 230 7/16" Quick Change
333NC.10142302 14 160 230 7/16" Quick Change
333NC.10152302 15 160 230 7/16" Quick Change
333NC.10162302 16 160 230 7/16" Quick Change
333NC.10182302 18 160 230 7/16" Quick Change
333NC.10192302 19 160 230 7/16" Quick Change
333NC.10202302 20 160 230 7/16" Quick Change
333NC.10212302 21 160 230 7/16" Quick Change
333NC.10222302 22 160 230 7/16" Quick Change
333NC.10242302 24 160 230 7/16" Quick Change
333NC.10252302 25 160 230 7/16" Quick Change
333NC.10262302 26 160 230 7/16" Quick Change
333NC.10272302 27 160 230 7/16" Quick Change
333NC.10282302 28 160 230 7/16" Quick Change
333NC.10302302 30 160 230 7/16" Quick Change
333NC.10322302 32 160 230 7/16" Quick Change
333NC.10332302 33 160 230 7/16" Quick Change
333NC.10342302 34 160 230 7/16" Quick Change
333NC.10352302 35 160 230 7/16" Quick Change
333NC.10362302 36
 160 230 7/16" Quick Change
Item Number Diameter(mm) Spiral flute length(mm) Overall Length(mm) Quick Change Hex Shank Standard
333NC.10064602 6 390 460 DIN6.35E
333NC.10074602 7 390 460 DIN6.35E
333NC.10084602 8 390 460 DIN6.35E
333NC.10094602 9 390 460 DIN6.35E
333NC.10104602 10 390 460 DIN6.35E
333NC.10114602 11 390 460 DIN6.35E
333NC.10124602 12 390 460 DIN6.35E
333NC.10134602 13 390 460 7/16" Quick Change
333NC.10144602 14 390 460 7/16" Quick Change
333NC.10154602 15 390 460 7/16" Quick Change
333NC.10164602 16 390 460 7/16" Quick Change
333NC.10184602 18 390 460 7/16" Quick Change
333NC.10194602 19 390 460 7/16" Quick Change
333NC.10204602 20 390 460 7/16" Quick Change
333NC.10214602 21 390 460 7/16" Quick Change
333NC.10224602 22 390 460 7/16" Quick Change
333NC.10244602 24 390 460 7/16" Quick Change
333NC.10254602 25 390 460 7/16" Quick Change
333NC.10264602 26 390 460 7/16" Quick Change
333NC.10274602 27 390 460 7/16" Quick Change
333NC.10284602 28 390 460 7/16" Quick Change
333NC.10304602 30 390 460 7/16" Quick Change
333NC.10324602 32 390 460 7/16" Quick Change
333NC.10334602 33 390 460 7/16" Quick Change
333NC.10344602 34 390 460 7/16" Quick Change
333NC.10354602 35 390 460 7/16" Quick Change
333NC.10364602 36
 390 460 7/16" Quick Change
Item Number Diameter(mm) Spiral flute length(mm) Overall Length(mm) Hex Shank Diameter(mm)
333NC.10066002 6 530 600 DIN6.35E
333NC.10076002 7 530 600 DIN6.35E
333NC.10086002 8 530 600 DIN6.35E
333NC.10096002 9 530 600 DIN6.35E
333NC.10106002 10 530 600 DIN6.35E
333NC.10116002 11 530 600 DIN6.35E
333NC.10126002 12 530 600 DIN6.35E
333NC.10136002 13 530 600 7/16" Quick Change
333NC.10146002 14 530 600 7/16" Quick Change
333NC.10156002 15 530 600 7/16" Quick Change
333NC.10166002 16 530 600 7/16" Quick Change
333NC.10186002 18 530 600 7/16" Quick Change
333NC.10196002 19 530 600 7/16" Quick Change
333NC.10206002 20 530 600 7/16" Quick Change
333NC.10216002 21 530 600 7/16" Quick Change
333NC.10226002 22 530 600 7/16" Quick Change
333NC.10246002 24 530 600 7/16" Quick Change
333NC.10256002 25 530 600 7/16" Quick Change
333NC.10266002 26 530 600 7/16" Quick Change
333NC.10276002 27 530 600 10.9
333NC.10286002 28 530 600 7/16" Quick Change
333NC.10306002 30 530 600 7/16" Quick Change
333NC.10326002 32 530 600 7/16" Quick Change
333NC.10336002 33 530 600 7/16" Quick Change
333NC.10346002 34 530 600 7/16" Quick Change
333NC.10356002 35 530 600 7/16" Quick Change
333NC.10360602 36
 530 600 7/16" Quick Change
