Mortise Chisel&Bit

1, Made from special carbon steel, these excellent-quality chisel-and-bit sets are attractively priced. The chisel bodies, accurately ground and hardened to Rc47-51, have polished outside faces and smoothly machined inner bevels.
2, Designed for efficient chip ejection, the drill bits have well-ground cutting tips and spurs, and are extra long (between 8 3/4" and 11" overall) for compatibility with a variety of mortisers. Although the lower sections of the drills are Rc50-54, the shanks are soft enough to be easily docked if required (instructions included).
3, For easy maintenance, we offer a pair of diamond sharpeners (available separately), one for the basic grind and the other to put a micro-bevel on the chisel corners.
4, This set is specially designed to match the size range and geometry of this series of chisels.
  • 325 Series

  • HTT, or OEM job

  • MPP

  • To cut square holes in various wood, plywood, etc.

  • 325

  • 6.35 to 25.4mm

  • Cylinder

  • Wood work

Availability:
Quantity:

Size Table:

Item Number Diameter(mm) Diameter(inch) Working Length(mm) Overall Length(mm)
325.10618501 6.35 1/4" 110 185
325.10818501 7.93 5/16" 110 185
325.11021001 9.52 3/8" 140 210
325.11121001 11.11 7/16"
140 210
325.11321001 12.7 1/2" 140 210
325.11421001 14 9/16" 140 210
325.11621001 15.88 5/8" 140 210
325.11922501 19.05 3/4" 160 225
325.12222501 22.22 7/8" 160 225
325.12522501 25.4 1" 160 225
