903 Series
HTT , OEM job
HPP
To drill holes in various steel, metal, iron, alloyed metal, unalloyed metal, non-ferrous metal, etc.
903 Series
2mm to 13mm
Cylinder
Metal work, Wood work
| Quantity: | |
|---|---|
Size table:
| Item Number | Diameter(mm) | Working Length(mm) | Overall Length(mm) |
| 903.340015 | 1.5 | 45 | 70 |
| 903.340020 | 2 | 56 | 85 |
| 903.340025 | 2.5 | 62 | 95 |
| 903.340030 | 3 | 66 | 100 |
| 903.340032 | 3.2 | 69 | 106 |
| 903.340033 | 3.3 | 69 | 106 |
| 903.340034 | 3.4 | 73 | 112 |
| 903.340035 | 3.5 | 73 | 112 |
| 903.340038 | 3.8 | 78 | 119 |
| 903.340040 | 4 | 78 | 119 |
| 903.340041 | 4.1 | 78 | 119 |
| 903.340042 | 4.2 | 78 | 119 |
| 903.340045 | 4.5 | 82 | 126 |
| 903.340048 | 4.8 | 87 | 132 |
| 903.340050 | 5 | 87 | 132 |
| 903.340051 | 5.1 | 87 | 132 |
| 903.340052 | 5.2 | 87 | 132 |
| 903.340055 | 5.5 | 91 | 139 |
| 903.340057 | 5.7 | 91 | 139 |
| 903.340058 | 5.8 | 91 | 139 |
| 903.340060 | 6 | 91 | 139 |
| 903.340065 | 6.5 | 97 | 148 |
| 903.340068 | 6.8 | 102 | 156 |
| 903.340070 | 7 | 102 | 156 |
| 903.340075 | 7.5 | 102 | 156 |
| 903.340080 | 8 | 109 | 165 |
| 903.340085 | 8.5 | 109 | 165 |
| 903.340090 | 9 | 115 | 175 |
| 903.340095 | 9.5 | 115 | 175 |
| 903.340100 | 10 | 121 | 184 |
| 903.340102 | 10.2 | 121 | 184 |
| 903.340105 | 10.5 | 121 | 184 |
| 903.340110 | 11 | 128 | 195 |
| 903.340112 | 11.5 | 128 | 195 |
| 903.340120 | 12 | 134 | 205 |
| 903.340125 | 12.5 | 134 | 205 |
| 903.340130 | 13 | 134 | 205 |
