939 Series
OEM, 3WIN, HTT
MPP+
To drill holes in various alloyed, unalloyed steel, rough metal , stainless steel, inox, iron, castiron,etc.
939
1.0 to 10mm
Cylindrical
Metal work
| Quantity: | |
|---|---|
Size Table:
| Item Number | Tip Diameter(mm) | Tip Cutter Length(mm) | Shank Diameter(mm) | Overall Length(mm) |
| 939.010032 | 1.00 | 1.9 | 3.15 | 31.5 |
| 939.012032 | 1.25 | 2.2 | 3.15 | 31.5 |
| 939.016036 | 1.60 | 2.8 | 4.00 | 35.5 |
| 939.020040 | 2.00 | 3.3 | 5.00 | 40.0 |
| 939.025045 | 2.50 | 4.1 | 6.30 | 45.0 |
| 939.032050 | 3.15 | 4.9 | 8.00 | 50.0 |
| 939.040056 | 4.00 | 6.2 | 10.00 | 56.0 |
| 939.050063 | 5.00 | 7.5 | 12.50 | 63.0 |
| 939.063071 | 6.30 | 9.2 | 16.00 | 71.0 |
| 939.080080 | 8.00 | 11.5 | 20.00 | 80.0 |
| 939.100100 | 10.00 | 14.2 | 25.00 | 100.0 |
Size Table:
| Item Number | Tip Diameter(mm) | Tip Cutter Length(mm) | Shank Diameter(mm) | Overall Length(mm) |
| 939.010032 | 1.00 | 1.9 | 3.15 | 31.5 |
| 939.012032 | 1.25 | 2.2 | 3.15 | 31.5 |
| 939.016036 | 1.60 | 2.8 | 4.00 | 35.5 |
| 939.020040 | 2.00 | 3.3 | 5.00 | 40.0 |
| 939.025045 | 2.50 | 4.1 | 6.30 | 45.0 |
| 939.032050 | 3.15 | 4.9 | 8.00 | 50.0 |
| 939.040056 | 4.00 | 6.2 | 10.00 | 56.0 |
| 939.050063 | 5.00 | 7.5 | 12.50 | 63.0 |
| 939.063071 | 6.30 | 9.2 | 16.00 | 71.0 |
| 939.080080 | 8.00 | 11.5 | 20.00 | 80.0 |
| 939.100100 | 10.00 | 14.2 | 25.00 | 100.0 |
