30022
HTT, OEM, 3WIN
OPP
To drill holes in various concrete, stone, brick, masonry building material,etc.
30022
3-25mm
Cylindrical
Masonry work
| Quantity: | |
|---|---|
Size Table:
| Item Number | Diameter（mm） | Working Length（mm） | Overall Length（mm） | Shank Diameter（mm） |
| 30022.030060 | 3 | 30 | 60 | 2.8 |
| 30022.030070 | 3 | 35 | 70 | 2.8 |
| 30022.030085 | 3 | 45 | 85 | 2.8 |
| 30022.035060 | 3.5 | 30 | 60 | 2.8 |
| 30022.035070 | 3.5 | 35 | 70 | 2.8 |
| 30022.040075 | 4 | 35 | 75 | 3.75 |
| 30022.040085 | 4 | 45 | 85 | 3.75 |
| 30022.040090 | 4 | 50 | 90 | 3.75 |
| 30022.040150 | 4 | 110 | 150 | 3.75 |
| 30022.045075 | 4.5 | 35 | 75 | 4 |
| 30022.045085 | 4.5 | 45 | 85 | 4 |
| 30022.050090 | 5 | 45 | 90 | 4.5 |
| 30022.050095 | 5 | 50 | 95 | 4.5 |
| 30022.050100 | 5 | 60 | 100 | 4.5 |
| 30022.050150 | 5 | 110 | 150 | 4.5 |
| 30022.050200 | 5 | 130 | 200 | 4.5 |
| 30022.050250 | 5 | 200 | 250 | 4.5 |
| 30022.050300 | 5 | 250 | 300 | 4.5 |
| 30022.050400 | 5 | 260 | 400 | 4.5 |
| 30022.050500 | 5 | 360 | 500 | 4.5 |
| 30022.055085 | 5.5 | 45 | 85 | 5 |
| 30022.055095 | 5.5 | 50 | 95 | 5 |
| 30022.055100 | 5.5 | 60 | 100 | 5 |
| 30022.055150 | 5.5 | 110 | 150 | 5 |
| 30022.060100 | 6 | 60 | 100 | 5.5 |
| 30022.060150 | 6 | 110 | 150 | 5.5 |
| 30022.060200 | 6 | 130 | 200 | 5.5 |
| 30022.060260 | 6 | 190 | 260 | 5.5 |
| 30022.060300 | 6 | 230 | 300 | 5.5 |
| 30022.060400 | 6 | 340 | 400 | 5.5 |
| 30022.060600 | 6 | 460 | 600 | 5.5 |
| 30022.065100 | 6.5 | 60 | 100 | 6 |
| 30022.065150 | 6.5 | 110 | 150 | 6 |
| 30022.065200 | 6.5 | 130 | 200 | 6 |
| 30022.065260 | 6.5 | 190 | 260 | 6 |
| 30022.065300 | 6.5 | 230 | 300 | 6 |
| 30022.065400 | 6.5 | 340 | 400 | 6 |
| 30022.070100 | 7 | 60 | 100 | 6.5 |
| 30022.070120 | 7 | 80 | 120 | 6.5 |
| 30022.070150 | 7 | 110 | 150 | 6.5 |
| 30022.070200 | 7 | 130 | 200 | 6.5 |
| 30022.070300 | 7 | 230 | 300 | 6.5 |
| 30022.070400 | 7 | 340 | 400 | 6.5 |
| 30022.070500 | 7 | 360 | 500 | 6.5 |
| 30022.075100 | 7.5 | 60 | 100 | 6.5 |
| 30022.075120 | 7.5 | 80 | 120 | 6.5 |
| 30022.075150 | 7.5 | 110 | 150 | 6.5 |
| 30022.080120 | 8 | 80 | 120 | 7.6 |
| 30022.080150 | 8 | 110 | 150 | 7.6 |
| 30022.080200 | 8 | 130 | 200 | 7.6 |
| 30022.080260 | 8 | 190 | 260 | 7.6 |
| 30022.080300 | 8 | 230 | 300 | 7.6 |
| 30022.080400 | 8 | 340 | 400 | 7.6 |
| 30022.080600 | 8 | 460 | 600 | 7.6 |
| 30022.085120 | 8.5 | 80 | 120 | 8 |
| 30022.085150 | 8.5 | 110 | 150 | 8 |
| 30022.085200 | 8.5 | 130 | 200 | 8 |
| 30022.090120 | 9 | 80 | 120 | 8 |
| 30022.090150 | 9 | 110 | 150 | 8 |
| 30022.095120 | 9 | 80 | 120 | 9 |
| 30022.095150 | 9 | 110 | 150 | 9 |
| 30022.100120 | 10 | 80 | 120 | 9 |
| 30022.100150 | 10 | 110 | 150 | 9 |
| 30022.100200 | 10 | 135 | 200 | 9 |
| 30022.100260 | 10 | 190 | 260 | 9 |
| 30022.100300 | 10 | 230 | 300 | 9 |
| 30022.100400 | 10 | 340 | 400 | 9 |
| 30022.100600 | 10 | 460 | 600 | 9 |
| 30022.110120 | 11 | 80 | 120 | 9 |
| 30022.110150 | 11 | 110 | 150 | 9 |
| 30022.110200 | 11 | 135 | 200 | 9 |
| 30022.115120 | 11.5 | 80 | 120 | 9.98 |
| 30022.115150 | 11.5 | 110 | 150 | 9.98 |
| 30022.115200 | 11.5 | 135 | 200 | 9.98 |
| 30022.120130 | 12 | 80 | 130 | 9.98 |
| 30022.120150 | 12 | 90 | 150 | 9.98 |
| 30022.120200 | 12 | 150 | 200 | 9.98 |
| 30022.120260 | 12 | 150 | 260 | 9.98 |
| 30022.120300 | 12 | 230 | 300 | 9.98 |
| 30022.120400 | 12 | 340 | 400 | 9.98 |
| 30022.120600 | 12 | 460 | 600 | 9.98 |
| 30022.121000 | 12 | 900 | 1000 | 9.98 |
| 30022.125130 | 12.5 | 80 | 130 | 9.98 |
| 30022.125150 | 12.5 | 90 | 150 | 9.98 |
| 30022.125200 | 12.5 | 150 | 200 | 9.98 |
| 30022.130150 | 13 | 90 | 150 | reduced 9.5 |
| 30022.130200 | 13 | 150 | 200 | reduced 9.5 |
| 30022.130300 | 13 | 230 | 300 | reduced 9.5 |
| 30022.135150 | 13.5 | 90 | 150 | reduced 9.5 |
| 30022.135200 | 13.5 | 150 | 200 | reduced 9.5 |
| 30022.140150 | 14 | 90 | 150 | reduced 9.5 |
| 30022.140200 | 14 | 135 | 200 | reduced 9.5 |
| 30022.140260 | 14 | 200 | 260 | reduced 9.5 |
| 30022.140300 | 14 | 230 | 300 | reduced 9.5 |
| 30022.140400 | 14 | 340 | 400 | reduced 9.5 |
| 30022.140600 | 14 | 460 | 600 | reduced 9.5 |
| 30022.145150 | 14.5 | 90 | 150 | reduced 9.5 |
| 30022.145200 | 14.5 | 135 | 200 | reduced 9.5 |
| 30022.150150 | 15 | 90 | 150 | reduced 9.5 |
| 30022.150200 | 15 | 135 | 200 | reduced 9.5 |
| 30022.160150 | 16 | 90 | 150 | reduced 9.5 |
| 30022.160200 | 16 | 135 | 200 | reduced 9.5 |
| 30022.160250 | 16 | 200 | 260 | reduced 9.5 |
| 30022.160300 | 16 | 230 | 300 | reduced 9.5 |
| 30022.160400 | 16 | 340 | 400 | reduced 9.5 |
| 30022.160600 | 16 | 460 | 600 | reduced 9.5 |
| 30022.180160 | 18 | 100 | 160 | reduced 9.5 |
| 30022.180200 | 18 | 135 | 200 | reduced 9.5 |
| 30022.180300 | 18 | 230 | 300 | reduced 9.5 |
| 30022.180400 | 18 | 340 | 400 | reduced 9.5 |
| 30022.180600 | 18 | 460 | 600 | reduced 9.5 |
| 30022.190160 | 19 | 100 | 160 | reduced 9.5 |
| 30022.190200 | 19 | 135 | 200 | reduced 9.5 |
| 30022.200160 | 20 | 100 | 160 | reduced 9.5 |
| 30022.200200 | 20 | 135 | 200 | reduced 9.5 |
| 30022.200260 | 20 | 200 | 260 | reduced 9.5 |
| 30022.200300 | 20 | 230 | 300 | reduced 9.5 |
| 30022.200400 | 20 | 340 | 400 | reduced 9.5 |
| 30022.200600 | 20 | 460 | 600 | reduced 9.5 |
| 30022.220160 | 22 | 100 | 160 | reduced 9.5 |
| 30022.220200 | 22 | 135 | 200 | reduced 9.5 |
| 30022.220300 | 22 | 230 | 300 | reduced 9.5 |
| 30022.220400 | 22 | 340 | 400 | reduced 9.5 |
| 30022.220600 | 22 | 460 | 600 | reduced 9.5 |
| 30022.250160 | 25 | 100 | 160 | reduced 12.7 |
| 30022.250200 | 25 | 135 | 200 | reduced 12.7 |
| 30022.250300 | 25 | 230 | 300 | reduced 12.7 |
| 30022.250400 | 25 | 340 | 400 | reduced 12.7 |
| 30022.250600 | 25 | 460 | 600 | reduced 12.7 |
